Basic Info.
Model NO.
ISSL-BRZ-40W
Illumination Time
>12 Hours
Cell Type
LiFePO4 Lithium
Charging Time (H)
5 Hours
Usage
Garden, Street, Highway
IP Rating
IP66
Certification
CE, RoHS, IP66
Voltage
12/24V
With Light Source
With Light Source
Transport Package
Customary Carton/ OEM Acceptable
Specification
1135*295*140mm
Trademark
ESAVIOR / ODM
Origin
China (Mainland)
HS Code
9405409000
Production Capacity
50, 000 Sets/Year
Product Description
ESAVIOR GREEN ENERGY, which supply 5W-200W solar led street light, solar garden light, solar flood light, and off-grid solar system, etc.
For all rang products please visit our website: esavior.en.made-in-china.com to download brochure & specification & user manual.
Advantages of Solar Street Light
Wireless Application:
Integrated solar panel, LED, lithium battery, micro-controller and other accessories into one system, simple and stylish.
Micro-Computer Controlled:
Combine light control system and time control system perfectly, ensure whole system more energy-efficient.
Easy Installation:
No power required, no cables required, easy installation in 5 minutes.
Good Heat Dissipation:
The shell is aluminum with scientific cooling hole, and also built-in aluminum block on the back of the light source to support good heat dissipation .
Extreme light:
Light efficiency reach 195 lm/w, at same watt ,more more Bright ,lighting area is expanded and more uniformity
Lithium battery:
Adopt LiFePO4 lithium battery to replace MnNiCo lithium battery, More than 8 years lifespan,longer lifetime.
Modular design:
All components are modular design and in standardized production. Battery can be easily replaced if needed.
Low cost:
Compared with traditional solar led lights, much lower cost, easy to transport.
| BRONZE Series | MODEL NO. ISSL-BRZ-40W | |||
| Solar Panel | Power | 18V/60Wp (Monocrystalline PV) | ||
| Life-span | 25 years | |||
| Batteries | Capacity/Type | 12.8V/18AH (230.40WH) / LiFePO4 Lithium | ||
| Life-span | 8+ years (3000 circles @60% DoD) | |||
| Controller | Type | MPPT / IP68/IoT Online Monitoring as Optional | ||
| Sensor | Microwave Radar (PIR & Timing as optional) | |||
| LED Light Source | Rated Power | 12V/ 40W (36LEDsx2 modules) | ||
| LED Brand | 3030 (LED Lumen: 195lm/W) | |||
| Lumens(LM) | 3600-4000lm | |||
| Life-span | 100,000 hours | |||
| Viewing Angle | 140° (Customized Angles & IES Types Available) | |||
| Full Charge Time | By Solar | 4 hours (STC: 1000W/m2, 25ºC ) | ||
| Discharge Time | Dim Mode | > 55 hours | ||
| Bright Mode | > 11 hours | |||
| Working Temp. | -30ºC~+80ºC | |||
| Color Temp. | Daylight White 5000K (full color temp. range 2700~6500K available) | |||
| Mounting Height/Brackets | 6~7 m/ Available Brackets: Post Top/ Arm/ Arm Tube/ Pole Clamps | |||
| Space Between Lights | 25~30m | |||
| Materials | aluminium alloy | |||
| Certificate | CE / ROHS / IP66/TUV-SUD ISO9001/ ISO14001 | |||
| Warranty | 3 years | |||
| Packing & Weight | Light Body Size: | 920*355*60mm | ||
| Net Weight | 15.0kg (Light: 12kg, bracket: 3kg) | |||
| Carton Type | Customary Carton/ OEM Acceptable | |||
| Carton size | Light: 960*400*200mm / Brackets: 900*350*190 | |||
| Qty/ctn | 2 lights in 1 CTN/ 6 brackets in 1 CTN | |||
| GW. per Carton | Light: 25.0kg/ Brackets: 19.0kgs | |||
| PCS per Container | 20' GP | 570 | ||
| 40' HQ | 1320 | |||
Applications:
1.Garden & Village square
2.Public areas &Parks & campus
3.Residential & Cummunity Center
4.Urban trunk road & Slow lane & Highway
5.Bike trails & Tourist attraction
6.City stadium & Office district
7.Rural & Remite Area Lighting
8.Housing Estates & Business Park
9.Retirement Village & Camping Lighting
WHY ESAVIOR?
1. 10 years' experience in with global successful project reference on the Solar Lighting field.
2. 13 patents core technologies were awarded to our Solar Street Lights and IoT online Monitoring System for Solar Street Light.
3. ISO 9001/14001, IEC 60598/ IES TM-21 / IES RP-27.3-07 reports were awarded by TUV-SUD besides our existing CE/RoHs/IP66 certificates.
4. More than 100 countries' clients enjoy our solar street led lights, highly praised by UNDP, UNHCR, UNOPS, Red Cross, The World Bank and government.
5. Provides a modern manufacturing base which meets international global solar RD & Inspection Center, has the most advanced inspection equipment and faultless QA system.
OVERSEAS EXHIBITION
SOLAR STREET LIGHT FAQ:
Q1:Does the lamp light on automatically?
A:Yes, it will light on automatically at darkness no matter which mode except "OFF".
Q2:Can I order samples for solar street light?
A:Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q3:What about the lead time?
A:3 workdays for sample, 7-15workdays for batch order(more than 100pcs).
Q4:Do you offer guarantee for the products?
A:Yes, we offer 3-5 years warranty to our products.
Q5:Can the lamp be used in strong wind environment?
A:Of course yes, as we take Aluminum-alloy holder, solid and firm, Zinc plated, anti- rust corrosion.
Q6:What's the difference between Motion sensor and PIR sensor?
A:Motion sensor also called radar sensor, works by emitting high frequency electric wave and detecting people movement.PIR sensor works by detecting environment temperature changing, which usually is 3-5 meters sensor distance.But motion sensor can reach 10 meters distance and be more accurate and sensitive.
Q7:How to deal with the faulty?
A:Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.5%.Secondly, during the guarantee period, we will send replacements with new order for small quantity.
