Basic Info.
Model NO.
KSD830C
Certification
CE, RoHS
Input Voltage
18V
With Light Source
With Light Source
LED Chips Brand
Bridgelux
Lumen
3000-3300lm
Solar Panel
18V 60W
Battery
Li-ion 3.7V 303wh/LiFePO4 3.2V 268wh
LED Life Time
50,000 Hours
Camera Pixel
1,100,000 Pixel
Video Transmission
WiFi
Storage
32g TF Card
Charging Time
8-10hours (with Enough Strong Shine)
Discharge Time
10-12 Hours Per Night 3-5rainy Days
Transport Package
Standard Export Carton Packaging/as Requirement
Specification
1198*315*206 mm
Trademark
KingSun
Origin
Nanjing, China
HS Code
940540900
Production Capacity
10000/Month
Product Description
Detail Information:
Advantage of Integrated Solar Street Light
1 Independent installation,flexible and easy,no need to dig trench,connection layout and backfill,saving construction costs.
2 No need extra enhancement equipment,saving costs of related parts.
3 Automatic controlling without people management,saving power and management costs.
4 PIR motion sensor system,lover power consumption,long time keeping,high brightness and long lifespan.
5 Take energy from the sun,saving energy and environmental protection,saving operation costs.
6 High-efficient storage lithium battery ,lightweight,small volume and large capacity,high times of charging and discharging
7 Easy maintenance,safe using,no danger of electric shock.
Working principle of integrated solar street light
Integrated street light mainly includes high efficiency Solar panel,Lithium Battery(LiFePO4),Intelligent Controller and Imported LED Chip.
During the day,the solar cells absorb the energy generated by solar photons,charge the lithium battery pack through intelligent controller,when night falls or the light intensity around the lamp is low or reaching to the limited time,lithium battery pack provide power to led lamps by controller and the lamp working
Company Profile
Nanjing KingSun Solar Technology Co.,Ltd is a professional manufacturer of Solar Module,Solar Power system,Integrated Street Light and Solar Lights Series products in China that located at Nanjing City.
Our products are exported to Europe,Middle east, Africa,South America and other Asia countries with TUV,IEC61215&61730,ISO and CE international standard,also we have flexible and timely after sales services.We offer high quality products and sustainable service to our customers,establishing a long-term cooperative relationship with them.
Through the continuous technological innovation and expanding of the productions scale,KingSun Solar continuing to lower manufacturing costs of solar mosules to make the unexhaustible and green solar energy to step in thousands of households,and create a better tomorrow for human development!
KingSun Solar carry out enterprise culture of "integrity, innovation, university, pioneering,' and the spirit of "one earth, one home, solar change the future" is our permanent pursuit,our practical attitude and accountability make our team work more efficient and more competitive.
Why choose KingSun
1. multiple choices We manufacture both Mono-crystalline and Poly-crystalline solar panels, models range from 0.1W to 320W. Epoxy panels from 0.1W to 2W, glass laminated panels from 3W to 300W.
2. No MOQ limited. Sample and small orders are acceptable.
3. Solar panels with your brand name are acceptable
4. Professional service
No matter residential, big commercial or government projects, you will receive our fully support by high quality and the most competitive price.
We also provide professional suggestions to you and give you best solutions.
5. With fully-automatic laminator and fully-automatic welding machine, all solar panels made with excellent looking and performances
| Solar street light 30W | Model: KSD830C | ||||
| Main Lamps material | Aluminium Alloy | ||||
| Solar panel | Max Power | 18V60W | |||
| Battery | li-ion battery | 3.7V 303WH | |||
| LiFePO4 battery | 3.2V 268WH | ||||
| LED | Led chip brand | Bridgelux from USA with high brightness | |||
| Lumen(LM) | 3000-3300LM | ||||
| CCT (k) | 6000-7000k | ||||
| Life Time | 50000 hours | ||||
| Camera | Pixel | 1,100,000 pixel | |||
| Video Compression | H.264 Main Profile & Baseline profile compression algorithm, more clear, less code flow, easy to network transmission | ||||
| Network function | 1,Support the double stream monitor at the same time; 2,Support mobile phone to see; 3,Support 6 users monitor the IP Camera at the same time; 4,Build-in WEB SERVER, Support IE browse and parameter setting, use one port for data transmitting, making it easy for users to network Settings; 5,Support 802.11b/g/n agreement,can be built-in wifi module, Flexible forming wireless monitoring environment; 6,Supports four regional Motion Detection and alarm linkage call presets; | ||||
| storage | 32G TF card | ||||
| Interface | WIFI | ||||
| Lighting Viewing Angle | 140°×70° | ||||
| Working TEMP( ºC ) | -20°~+60° | ||||
| Working Mode | Sensoring Mode | ||||
| Charge time(by sun): | 8-10hours (with enough strong shine) | ||||
| Discharge time | 10-12 hours per night 3-5rainy days | ||||
| Certificate | CE/ROHS/IP66 | ||||
| Packing | Product size | 1198*315*206 mm | |||
| Packing size | Box 1:1310*390*230 mm(lamp body) Box 2 :350*290*220mm(Supportor+Accessories) | ||||
| Packing way | 1sets/2carton | ||||
| Packs Containers | 20ft container | 395pcs | |||
| 40gp container | 762pcs | ||||
| Installation height | 7-8meters | Suggestion distance | 25-30meters | ||
Advantage of Integrated Solar Street Light
1 Independent installation,flexible and easy,no need to dig trench,connection layout and backfill,saving construction costs.
2 No need extra enhancement equipment,saving costs of related parts.
3 Automatic controlling without people management,saving power and management costs.
4 PIR motion sensor system,lover power consumption,long time keeping,high brightness and long lifespan.
5 Take energy from the sun,saving energy and environmental protection,saving operation costs.
6 High-efficient storage lithium battery ,lightweight,small volume and large capacity,high times of charging and discharging
7 Easy maintenance,safe using,no danger of electric shock.
Working principle of integrated solar street light
Integrated street light mainly includes high efficiency Solar panel,Lithium Battery(LiFePO4),Intelligent Controller and Imported LED Chip.
During the day,the solar cells absorb the energy generated by solar photons,charge the lithium battery pack through intelligent controller,when night falls or the light intensity around the lamp is low or reaching to the limited time,lithium battery pack provide power to led lamps by controller and the lamp working
Company Profile
Nanjing KingSun Solar Technology Co.,Ltd is a professional manufacturer of Solar Module,Solar Power system,Integrated Street Light and Solar Lights Series products in China that located at Nanjing City.
Our products are exported to Europe,Middle east, Africa,South America and other Asia countries with TUV,IEC61215&61730,ISO and CE international standard,also we have flexible and timely after sales services.We offer high quality products and sustainable service to our customers,establishing a long-term cooperative relationship with them.
Through the continuous technological innovation and expanding of the productions scale,KingSun Solar continuing to lower manufacturing costs of solar mosules to make the unexhaustible and green solar energy to step in thousands of households,and create a better tomorrow for human development!
KingSun Solar carry out enterprise culture of "integrity, innovation, university, pioneering,' and the spirit of "one earth, one home, solar change the future" is our permanent pursuit,our practical attitude and accountability make our team work more efficient and more competitive.
Why choose KingSun
1. multiple choices
2. No MOQ limited. Sample and small orders are acceptable.
3. Solar panels with your brand name are acceptable
4. Professional service
No matter residential, big commercial or government projects, you will receive our fully support by high quality and the most competitive price.
We also provide professional suggestions to you and give you best solutions.
5. With fully-automatic laminator and fully-automatic welding machine, all solar panels made with excellent looking and performances
