Basic Info.
Model NO.
ELS-ST09
Power
50W 60W 80W 100W 120W 150W
Application
Square, Highway, Garden, Parking Lot, Pathway
IP Rating
IP66
Certification
CE, RoHS
Input Voltage
12V/24V
With Light Source
With Light Source
LED Chips Brand
Bridgelux
Solar Panel Voltage
18V
LED Lumens
210lm/W
Beam Angle
140*70°
Lighting Mode
Auto on/off &Time Control & Sensor
LED Brand
Bridgelux
Solar Panel
Monocrystalline,25 Years Lifetime,21% Efficiency
Sensor
Smart Motion Sensor
Lifetime of Solar Panel
25 Years
Lighting Time
12 Hours Lighting Per Night
LED Type
SMD3030
Transport Package
Carton
Specification
1 Pieces/ Carton
Trademark
ELLINS
Origin
Guangdong, China
HS Code
940542
Production Capacity
50000PCS/Year
Packaging & Delivery
Package Size
168.00cm * 47.00cm * 17.00cm
Package Gross Weight
22.000kg
Product Description
Main Features:
*High class Integrated die-casting Aluminum alloy case .
*Lighting mode use intelligence radar senor,sensor long distance.
*140*70° view angle,lighting more area.
*Easy to install,maintance,Auto on/off
*The controller recognizes day and night based on the solar array open circuit voltage
| Model | ELS-ST09 | |||||
| Power | 50W | 60W | 80W | 100W | 120W | 150W |
| LED QTY | 100pcs | 100pcs | 150pcs | 200pcs | 250pcs | 250pcs |
| Battery | 72AH | 90AH | 108AH | 120AH | 144AH | 168AH |
| Solar Panel | Mono | Mono | Mono | Mono | Mono | Mono |
| 60W | 60W | 80W | 100W | 110W | 120W | |
| Mounting Height | 5~6m | 6~7m | 7~8m | 8~10m | 8~10m | 9~10m |
| Voltage | 12/24V | |||||
| Material | Die casting aluminum housing +PC lens+Temprered glass | |||||
| LED | CREE/Bridegelux LED | |||||
| Lumen | 210lm/w | |||||
| working temperature | -25ºC~+65ºC | |||||
| Beam angel | 140*70° | |||||
| Warranty | 3 years | |||||
Accessories: 1pcs/ Lamp holder; 1pcs/ Remote Controll
Precautions
| 1. When installing lights, please take it lightly and gently, and it is strictly forbidden to collide or knock to avoid damage. 2.There should be no tall buildings or trees in front of the solar panels to shield the sunlight, and choose toinstall without cover.3.All the screws for installing the lamps need to be tightened and screwed tightly, and there should be noloosening. 4.Since the lighting time and power are set according to the factory specifications,if need specialightingmode should be notified before placing the order. 5.When repairing or replacing the led chip, lithium battery, controller,type and power must be the same asour original,lt is strictly forbidden to replace the light source with different power models from any othermanufacture. 6.When replacing internal parts, wiring must be strictly in accordance with the corresponding wiring diagram. The positive and negative poles are dlearly separated, and reverse connection is strictly prohibited. |
