Basic Info.
Model NO.
XT-SL-008
Lamp Body Material
Aluminum
Light Type
Solar
Color Temperature
Cool White
Power
≥30W
Technics
Painted Matte
Illumination Time
12h
Charging Time (H)
12
Usage
Garden, Street
IP Rating
IP67
Certification
CE, RoHS
Voltage
12/24V
With Light Source
With Light Source
Keyword
Solar Street Light
Charge Time
6-8 Hours
Working Temperature
-20 - 60
Service Life (Hours)
80000h
Color Rendering Index (Ra>)
75
Power Supply
Solar DC
Solar Panel
Monocrystalline Silicon
LED Chip
Bridgelux Chip 45mil
Dimension
640*250*70mm
Sensor
Motion Sensor + Light Sensor
LED Power
40W/60W/80W/100W/150W/200W
Pole
Hot-DIP Galvanized
Color Temperature(CCT)
Warm White
Working Lifetime(Hour)
80000
Battery
Lead-Acid Battery
Transport Package
Carton Box
Specification
14LM/W
Trademark
XINTONG
Origin
Jiangsu, Yangzhou
HS Code
9405409000
Production Capacity
200000
Packaging & Delivery
Package Size
1000.00cm * 700.00cm * 1000.00cm
Package Gross Weight
200.000kg
Product Description
Yangzhou Xintong Traffic Equipment Group Co., Ltd. is one of the earliest enterprises engaged in the manufacture of complete sets of traffic equipment. Established in 1999, Xintong has more than 340 employees and is engaged in intelligent transportation and security engineering. Always adhere to a specific development direction and product serialization. We put quality first; It is our responsibility to see smart transportation and safety projects as outstanding work; To our goal for users to establish a full range of services. So far, Xintong has become a large-scale enterprise integrating product design, production, sales, service and engineering.
Now the company has Jiangsu Province famous trademark, national high-tech enterprise, provincial Citic enterprise, security qualification, road lighting first-class qualification, 3C certification, Ministry of Public Security traffic lights, signal lights, electronic and intelligent engineering, information system integration and service level 3 qualification, safety production license, AAA credit and other industry qualification certificates. Products have a full series of municipal electric solar signal lights, intelligent coordinated signal network, signs, signs, induction screen, large dragon gate road span, induction screen pole and all kinds of conventional signal lights, electrical alarm, monitoring and personalized pole. Adhere to the continuous development of brand products and technological innovation, strengthen user services, train a large number of experienced talents, have an aggressive management team, for the company's long-term development has laid a reliable foundation.
| Solar Street Light Spec | |||
| Item | Detail | Spec | Lifespan |
| Solar Panel | 18.5% Efficiency;Poly Crystalline Silicon;High Efficiency;Adding Aluminum Frame, Tempered Glass. | 30W ~310W | 20~25 years |
| Gelled Battery | Sealed Type, Gelled;Deep cycle;Maintenance Free. | 24Ah~250Ah | 5~8 years |
| Intelligent Solar Controller | Automatic Light and Time Control;Over-charging/discharging Protection;Reverse-connection Protection;Switch on Automatically with Light Sensor;;Switch off after 11-12 Hrs later. | 10 / 15 / 20Ah | 5-8 years |
| LED Light Source | IP65,120 Degree Angle;High Power, High Brightness. | 10W~300W | 5-8 years |
| Lamp Housing | Die-casted Aluminum, IP65;High transmittance & density toughened glass. | 50cm~90cm | > 30 years |
| Pole | Steel, Hot-Dip Galvanized;With Arm, Bracket, Flange, Fittings, Cable, Etc;Plastic Coated, Rust Proof;Resistant to Wind: ≥150KM/H. | 3m~15m | > 30 years |
