Basic Info.
Model NO.
SMLN-30W
Application
Highway, Square, Garden
IP Rating
IP66
Certification
CE, RoHS, ISO, FCC, EMC, GS, TUV
Voltage
12V
Warranty(Year)
5 Years
Input Voltage(V)
DC12/24V
Lamp Luminous Efficiency(Lm/W)
180lm/W
Maintenance
8 Years Free Maintenance
Mounting Height
3m 4m 5m 6m 7m
CRI (Ra>)
75/80/85/90
LED Chip Brand
USA Bridgelux 210lm/W
Back up Days
3 Days
Lamp Luminous Flux(Lm)
180
Distance Between Poles
10-15m
Pole Height
7m From 5m to 12m
Solar Cells
Mono or Poly High Efficiency A Grade
Dim/Non-Dim
Both Can D
Approval
CE/RoHS/Coc/IEC Soncap
OEM/ODM/Customized
Available
Transport Package
Carton
Specification
886x450x140mm
Trademark
sunmaster
Origin
Zhejiang, China
HS Code
9405409000
Production Capacity
1000PCS/Week
Product Description
1.3-5 rainy /cloudy days backup
2.Dusk-to-Dawn 12 hours with dim energy saving mode
3.Lighting times can be individually adjusted with program switch.
4.Illuminance in operation depending on local site conditions (average daylight available) and customer-specific lighting times.
| Model NO. | SMLN-30W | Battery Type: | LiFePO4 24Ah/12.8V |
| Power: | 30W | Charging Time: | 6-10 hours |
| Color Temperature: | 6000-6500K | Discharging Time: | 10-12 hours |
| Certificate: | CE/ROHS/IP65 | Product Dimension: | 886*450*140mm |
| Viewing Angle: | 120 | Packing Dimension: | 940*510*200mm |
| Working temperature : | ,-20 ~ +70 | Product Weight | 17KG |
| Lamp Efficiency: | 170 lm/w | Material: | Aluminum Alloy |
| Led chip brand: | USA Bridgelux LED chip | Install Height: | 6-7 m |
| Solar Panel: | 18V 60W Mono-crystalalline | Warranty: | 3 years |
