Basic Info.
Power
30W-400W
Technics
Electroplating
Illumination Time
10h
Cell Type
Ni-MH Battery
Charging Time (H)
8
Usage
Garden, Street
IP Rating
IP65
Certification
CE, RoHS
Voltage
3-6V
With Light Source
With Light Source
Item No.
Rb-Sol-St03
CCT
3000K, 4000K, 5000K, 6500K
Power Factor(PF)
>0.9
Material
Aluminium Alloy
LED Efficiency
120lm/W
Fixture Efficiency
>95%
Warranty Time
2 Years Solar LED Street Light
IP Rate
IP66 Solar LED Street 200W 300W 400W
LED
Bridgelux
Battery
Lithium Battery (3.2V 36ah)
Packaging
Pearl Cotton Color Packaging
Transport Package
1PC/Carton
Specification
CE/ROHS
Trademark
RAYBORN
Origin
China
HS Code
9405409000
Production Capacity
60, 000PCS
Product Description
2021 New Design Aluminum Solar LED Light Area Outdoor LED Solar Street Light Super Bright High Lumens Security Solar Light Outdoor 100w 200w led solar light for Yard Garden Street Playgroud
Product Specifications:
Outdoor Solar LED Street light/Lamp
| 200W LED Solar Street Light Main Technical Parameters | |||
| Item No.: | RB-SOL-ST03-200W | ||
| Solar panel: | 5V / 40W (high efficiency polycrystalline silicon) | ||
| Battery: | Lithium battery (3.3V 48A) | ||
| LED PCS: | 200pcs | ||
| Charging time : | 5-8 hours | ||
| Color Temperature | Warm White | 3000-3500K | |
| Pure White | 4000-5500K | ||
| Cool White | 6500-7000K | ||
| Color Rendering Index | Ra>80 | ||
| Materials: | Aluminium Alloy | ||
| Discharging time: | Over 36 hours | ||
| LED Junction Temperature: | ≤115ºC | ||
| Working Temperature: | -35ºC~55ºC | ||
| IP Grade: | IP66 | ||
| Mounting height: | 4-8 meters | ||
| Space between lights: | 15-25M | ||
| Working Life-span: | 100000 H | ||
| Power Line: | 1.0 mm three line | ||
| Connect Wire | Brown | L | |
| Blue | N | ||
| Yellow / Green | G | ||
| Certificate | CE/ROHS | ||
| Housing color: | Grey | ||
| Producs Size: | 520X260X80mm | ||
Outdoor LED Solar Street light Feature :
LED Chip: Bridgelux LED Chips which is the most famous Brand in chips field, high efficiency and long lifespan>50000 hours .
Color temperature: LED Street light provide a range of color temperatures from 3000, 4000,5000 and 6000 Kelvin helping to enhance a building's exterior.
Optics: Optical assembly hermetically sealed providing IP65. LED optical systems the fixture maximize the utilization of light onto the target area, improving the uniformity of light.
Housing: Fishbone style high efficiency heat sink,elegant appearance .Die cast aluminum housing electrostatically sprayed with a polyester powder paint finish, following anti-corrosion priming, and oven cured at 180oC.
Cable: silicon rubber cable for power input. Fasten with screw in the cable gland.
Warranty: 3 years warranty on the entire luminaire. Do not attempt to take housing apart as this will ruin the seal and void all warranty.
Certification: FCC CE RoHS approval.
Quality Control: Rigorous product testing includes high-low temperature tests, waterproof tests, shockproof tests, burn-in testing, tensile test, salt spray test and more to ensure long-term performance.
Outdoor Solar LED Street light Competitive Advantage :
1. CE & RoHS & SAA IP66 approved, Quality Guaranteed
2. Imported original Bridgelux & Epistar chip, superior light source
3. OEM & ODM welcome, independent R&D ability, patent design.
4. Fast delivery, 3-15 workdays depends on order quantity after payment confirmed
5. Reliable quality & credit, 3 years warranty and 50.000 hours lifespan
Outdoor Solar LED Street light Applications:
1. Playground and stadium lighting.
2. Parking lot and airport lighting.
3. Highway and Railway tunnel lighting.
4. Bridge and culvert lighting.
5. Square,garden,and building lighting.
Outdoor Solar LED Street light 24hours AGING Tested :
Before shipping, all the LED streetlights will be over 24 hours aging tested, inspection department will test 100% products including light up test , power wattage test , high-voltage test , waterproof test , ground connection test and so on, defective rate is controlled less than 0.1%. Quality is ensured, you can be assured.
Rayborn Company viewing :
Rayborn Lighting Co.,Ltd is a professional manufacturer ,focus on Industrial LED lights and commerical LED lights research ,devolopment ,production,sales ,on service,was in High-end operation and service provider in High-power led .Under the country "saving "polics,we are striving to create environment protection ,energy saving ,long life lighting and earned a reputation of being a quality supplier of LED lighting .
We has a group of professional technical R & D team, who can provide the OEM / ODM services according to customers and LED lighting solutions,our factory has passed the authentications of ISO9001:2000,CE, FCC, ROSH ,TUV authentication.
Payment terms:
1. Payment: T/T, L/C at sight, Western Union ,Paypal available
2. Samples can be available within 5-7 working days; Order: 10-20Days
3. Shipping freight is quoted under your requests
4. Shipping port:Shenzhen , China
5. Discounts are offered based on order quantities
Rayborn services:
•1. Your inquiry related to our products or prices will be replied in 24hours.
•2. OEM & ODM are welcomed, OEM brand is available.
•3. Any defective products within warranty will get maintenance or replacement unconditionally.
•4. Protect your sales area
FAQ:
1. What is the general business process?
Answer : Send Inquiry to Rayborn. → Specification Confirmation → Quotation → Sample List Confirm → Proforma Invoice → Payment Bank Slip → Sample Delivery → Sample Satisfactory → Bulk Order List → Proforma Invoice → 30% Deposit Payment in Advance → Production Ready → 70% Balance bank slip → Delivery → After Sale Service
2. What is the warranty?
Answer : 3-5 years warranty is offered depending on different types of lights. If item fails due to quality problem during warranty, we can send new replacement with freight on ours immediately if urgently. Or we prefer to send replacement with next order.
3. What is the payment term?
Answer : For sample order, we can accept T/T, Paypal, West Union, 100% in advance.
For bulk order, 30% deposit in advance by T/T, 70% balance before shipping.
For very big order, L/C is negotiable.
4. Can I add my logo on the product label?
Answer : Yes, but order quantity is requested depending on different lights.
5. I don't know how many LED Street Light should I use, can you advise?
Answer : Yes, we can offer our professional solution for you, IES file is available if you have the design team.
6. Do you have any MOQ limit for led light order?
Answer: Low MOQ, 1pc for sample checking is available .
7. How do you ship the goods and how long does it take to arrive?
Answer: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
8. How to proceed an order for led light?
Answer : Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
9: How to deal with the faulty?
Answer : Firstly, Our products are produced in strict quality control system and the defective rate < 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity.
For defective batch products, we will send out new replacement to you immediately for you to solve the problem.
